SMP Connector

SMP connector is a small, high frequency RF connector typically used for connecting high frequency signal transmission in RF equipment. They have a high frequency range (typically from DC to 40 GHz) and excellent plugging and unplugging performance.

SMP connectors typically come in two forms: straight-through and PCB (printed circuit board). The straight-through type connects two coaxial cables or connectors, while the PCB type connects a printed circuit board. SMP connectors offer the advantages of miniaturization, high-frequency support, low insertion loss, good high-frequency characteristics, and highly stable mechanical properties.

Due to their excellent performance, SMP connectors are widely used in communications, radar systems, test instruments and other equipment requiring high frequency signal transmission. Their small size and excellent performance make them ideal for high performance RF connectors.

Connector Type: Plug
Contact Finish: Gold
Contact Material: Brass
Contact Type: Male Pin
Frequency Range: DC-18GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Finish: Gold Plated
Shell Material: Brass
Shield Termination: Solder
Connector Type: Jack
Contact Finish: Gold
Contact Material: Brass
Contact Type: Female Pin
Frequency Range: DC-18GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Finish: Gold Plated
Shell Material: Brass
Shield Termination: Solder
Connector Type: Jack
Contact Finish: Gold
Contact Material: Brass
Contact Type: Female Pin
Frequency Range: DC-18GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Finish: Gold Plated
Shell Material: Brass
Shield Termination: Solder
Connector Type: Jack
Contact Finish: Gold
Contact Material: Beryllium Bronze
Contact Type: Female Pin
Frequency Range: DC-40GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Finish: Gold Plated
Shell Material: Beryllium Bronze
Shield Termination: Solder
Connector Type: Jack
Contact Finish: Gold
Contact Material: Beryllium Bronze
Contact Type: Female Pin
Frequency Range: DC-40GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Finish: Gold Plated
Shell Material: Beryllium Bronze
Shield Termination: Solder
Connector Type: Jack
Contact Finish: Gold
Contact Material: Beryllium Bronze
Contact Type: Female Pin
Frequency Range: DC-40GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Finish: Gold Plated
Shell Material: Beryllium Bronze
Shield Termination: Solder
Connector Type: Jack
Contact Finish: Gold
Contact Material: Beryllium Bronze
Contact Type: Female Pin
Frequency Range: DC-40GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Finish: Gold Plated
Shell Material: Beryllium Bronze
Shield Termination: Solder
Connector Type: Plug
Contact Finish: Gold
Contact Material: Brass
Contact Type: Male Pin
Frequency Range: 0-6GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Finish: Gold Plated
Shell Material: Brass
Shield Termination: Solder
Connector Type: Plug
Contact Finish: Gold
Contact Material: Brass
Contact Type: Male Pin
Frequency Range: DC-18GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Finish: Gold Plated
Shell Material: Brass
Shield Termination: Solder
Connector Type: Plug
Contact Finish: Gold
Contact Material: Brass
Contact Type: Male Pin
Frequency Range: DC-40GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Finish: Gold Plated
Shell Material: Brass
Shield Termination: Solder
Connector Type: Plug
Contact Finish: Gold
Contact Material: Brass
Contact Type: Male Pin
Frequency Range: DC-26.5GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Material: Stainless Steel
Shield Termination: Solder
Connector Type: Plug
Contact Finish: Gold
Contact Material: Brass
Contact Type: Male Pin
Frequency Range: DC-26.5GHz
Impedance: 50 ohm
Insulator Material: PTFE
RF Series: SMP Type
Shell Material: Stainless Steel
Shield Termination: Solder
