Mini HSBridge USB 3.1 Type-C Automotive Data Transfer Cable – RHT-605-20869
Product Specification
| 1st Connector | USB 3.1 Type-C |
||
|---|---|---|---|
| 2nd Connector | USB 3.1 Type-C |
||
| 1st Contact Type | Male Pin |
||
| 2nd Contact Type | Male Pin |
||
| Cable Type | [30 AWG×1P+D+AL]×4 + 30 AWG×1P + 30 AWG×4C + 20 AWG×1C + Braid |
||
| Impedance | 90 ohm |
||
| Frequency Range | DC ~ 5 GHz |
||
| Temperature Range | -40°C to +105°C |
||
| Insulation Resistance | 100V/DC, 20 MΩ, Min For 10ms |
||
| 1st Connector | USB 3.1 Type-C |
2nd Connector | USB 3.1 Type-C |
| 1st Contact Type | Male Pin |
2nd Contact Type | Male Pin |
| Cable Type | [30 AWG×1P+D+AL]×4 + 30 AWG×1P + 30 AWG×4C + 20 AWG×1C + Braid |
Impedance | 90 ohm |
| Frequency Range | DC ~ 5 GHz |
Temperature Range | -40°C to +105°C |
| Insulation Resistance | 100V/DC, 20 MΩ, Min For 10ms |
| Length | Customized |
|---|---|
| Length | Customized |
| 1st Connector | USB 3.1 Type-C |
|---|---|
| 2nd Connector | USB 3.1 Type-C |
| 1st Contact Type | Male Pin |
| 2nd Contact Type | Male Pin |
| Cable Type | [30 AWG×1P+D+AL]×4 + 30 AWG×1P + 30 AWG×4C + 20 AWG×1C + Braid |
| Length | Customized |
| Impedance | 90 ohm |
| Frequency Range | DC ~ 5 GHz |
| Temperature Range | -40°C to +105°C |
| Insulation Resistance | 100V/DC, 20 MΩ, Min For 10ms |
Overview
Designed for high-density vehicle electronics, this HSBridge / Mini HSBridge to USB Type-C cable assembly delivers reliable high-speed differential signal transmission in space-constrained automotive environments. It connects compact ECU modules, telematics systems, and smart displays to standard USB Type-C architectures with superior mechanical retention.
Key Features & Benefits
- Miniaturized High-Density Interconnect: Features compact HSBridge / Mini HSBridge latching connectors, saving board space and reducing harness weight in tight automotive routing paths.
- Secure Secondary Latching: Equipped with mechanical keying codes and robust CPA (Connector Position Assurance) latches to prevent accidental disengagement during vehicle movement.
- Optimized High-Frequency Shielding: Engineered with fully shielded metallic shells and 360° continuous grounding to meet stringent EMC/RFI standards.
- Automotive Spec Cable Construction: High-flex, flame-retardant outer jacket designed for optimal routing around sharp internal vehicle panel edges.
Applications
- Telematics Control Units (T-Box) & Telematics Gateways
- Head-Up Displays (HUD) & Compact Instrument Panels
- Space-Constrained ECU-to-Display Signal Links
