HSD 4+4P Z Code Male R/A PCB Mount Connector for GMSL Video Link
- Right angle 4+4 pin HSD connector plug with panel mount, Z code, for reliable and high-speed data transmission in automotive and industrial systems
- Right angle design allows for efficient cable routing, reducing space requirements and minimizing strain on connections for stable performance
- Built to withstand mechanical stress, temperature fluctuations, and vibrations, ensuring long-term durability and reliable signal transmission
- Panel mount feature ensures secure, stable installation in a wide range of applications, including automotive, embedded systems, and industrial setups
- Supports high-speed HD video, audio, and data transmission, compatible with HSD systems for seamless connectivity in demanding environments
HSD connectors provide connectivity solutions for automotive infotainment modules, GMSL/GMSL2 cameras, consumer equipment ports, and display devices.
The HSD product portfolio is designed for high-speed data transmission to meet automotive requirements up to 6 Gbps. It is engineered to support leading SerDes protocols with superior signal integrity.
These connectors can be combined with GMSL2, LVDS, IEEE 1394, and USB 2.0. Our high-speed solutions are compatible with the German AK HSD interface and support protocols compliant with USCAR 30.
HSD plug and jack in schematic view with pin assignment
| Code | A | B | C | D | E | F | G |
| Color | Jet black | Cream | Signal blue | Claret violet | Leaf green | Nut brown | Blue grey |
| Male |  |
 |
 |
 |
 |
 |
 |
| Female |  |
 |
 |
 |
 |
 |
 |
| Code | H | J | K | L | M | O | Z |
| Color | Heather violet | Beige | Curry | Yellow green | Pastel orange | Pastel green | Water blue |
| Male |  |
 |
 |
 |
 |
 |
 |
| Female |  |
 |
 |
 |
 |
 |
 |
HSD stands for High Speed Data and is a high-density interface available in 1-pin, 4-pin, 6-pin (4+2), and 4+4 pin (Dual HSD) configurations to meet various data and power needs. The core 4-pin data interface is designed based on the “star-four principle”, where the opposite wires form a balanced wire pair to minimize crosstalk and EMI. As the name implies, HSD is dedicated to high-speed data transfer, offering high signal quality and interference safety for the demanding automotive industry. Key Applications:
