SMP Jack for 0.086″ Cable – RHT-628-2009
SMP jack, 50Ω, designed for 0.086″ semi-rigid cable with reliable crimp termination, compact body supports high-frequency signal routing, maintains consistent return loss up to 40 GHz, commonly used in microwave circuit boards and subsystem interconnections.
Product Specification
| RF Series | SMP Type |
||
|---|---|---|---|
| Orientation | Straight |
||
| Connector Type | Jack |
||
| Suitable Cable | 086 Cable |
||
| Contact Type | Female Pin |
||
| Contact Material | Beryllium Copper |
||
| Contact Finish | Gold Plated |
||
| Shell Material | Beryllium Copper |
||
| Shell Finish | Gold Plated |
||
| Insulator Material | PTFE |
||
| Impedance | 50 ohm |
||
| Frequency Range | DC-40GHz |
||
| VSWR | 1.4 MAX |
||
| RF Series | SMP Type |
Orientation | Straight |
| Connector Type | Jack |
Suitable Cable | 086 Cable |
| Contact Type | Female Pin |
Contact Material | Beryllium Copper |
| Contact Finish | Gold Plated |
Shell Material | Beryllium Copper |
| Shell Finish | Gold Plated |
Insulator Material | PTFE |
| Impedance | 50 ohm |
Frequency Range | DC-40GHz |
| VSWR | 1.4 MAX |
| RF Series | SMP Type |
|---|---|
| Orientation | Straight |
| Connector Type | Jack |
| Suitable Cable | 086 Cable |
| Contact Type | Female Pin |
| Contact Material | Beryllium Copper |
| Contact Finish | Gold Plated |
| Shell Material | Beryllium Copper |
| Shell Finish | Gold Plated |
| Insulator Material | PTFE |
| Impedance | 50 ohm |
| Frequency Range | DC-40GHz |
| VSWR | 1.4 MAX |
The SMP interface, similar in size to MMCX connectors, supports frequencies from DC to 40 GHz. Frequently employed in compact high-frequency coaxial modules, this interface comes in push-on and snap-on mating variations.
Features
- Full detent, limited detent, smooth bore or catcher’s mitt
- Standard surface mount (versus swept contact) for best performance
- 50 ohm impedance
- Performance to 40 GHz
- Cable-to-board or board-to-board applications
- Push-on interface for quick installation, or blind mate
SMP Connector Types
Cable Mount
Panel Mount
SMP Adaptor
Applications
- Antennas
- Broadband
- Instrumentation
- Medical
- Quantum Computing
