HMTD Male A Code R/A PCB Mount Connector

Name: HMTD Male A Code R/A PCB Mount Connector
Brand: Renhotec
SKU: 33-1402-1541-A

SKU 33-1402-1541-A Category Automotive Ethernet Connectors

Product Files

Open drawing and specification files.

Catalog PDF

OEM Compatibility & Manufacturer Part Number Reference

RenhotecRF 33-1402-1541-A can be used as a compatible alternative for the following manufacturer part numbers after drawing and mating-interface verification.

RenhotecRF Part No.	33-1402-1541-A
Rosenberger Part No.	E6S201-40MT5-A

Manufacturer names and part numbers are used for compatibility reference only. Final compatibility should be confirmed by drawing, key code, impedance, and mounting dimensions.

Product Type	Connector
Key Code	A
Mount Type	Board Mount
Position Count	2
Return loss	≥ 30 dB, DC to 1 GHz; TBD, DC to 15 GHz
Product Type	Connector	Key Code	A
Mount Type	Board Mount	Position Count	2
Return loss	≥ 30 dB, DC to 1 GHz; TBD, DC to 15 GHz

Product Specification

Cable Color	Black
Connector Type	Plug
Contact Finish	Gold Plated
Contact Material	Brass
Frequency - Max	DC to 10 GHz
Insulation Resistance	≥1000 MΩ
Insulator Material	PTFE
Orientation	Right Angle
Plastic Housing	PA66
Shell Finish	Nickel Plated
Shell Material	Brass
Temperature Range	-40 °C to +105 °C
Cable Color	Black	Connector Type	Plug
Contact Finish	Gold Plated	Contact Material	Brass
Frequency - Max	DC to 10 GHz	Insulation Resistance	≥1000 MΩ
Insulator Material	PTFE	Orientation	Right Angle
Plastic Housing	PA66	Shell Finish	Nickel Plated
Shell Material	Brass	Temperature Range	-40 °C to +105 °C

Product Type	Connector
Cable Color	Black
Connector Type	Plug
Contact Finish	Gold Plated
Contact Material	Brass
Frequency - Max	DC to 10 GHz
Insulation Resistance	≥1000 MΩ
Insulator Material	PTFE
Key Code	A
Mount Type	Board Mount
Orientation	Right Angle
Plastic Housing	PA66
Position Count	2
Return loss	≥ 30 dB, DC to 1 GHz; TBD, DC to 15 GHz
Shell Finish	Nickel Plated
Shell Material	Brass
Temperature Range	-40 °C to +105 °C

H-MTD Automotive Ethernet Connectors

H-MTD is a differential connector system for high-speed data transmission of up to 20 GHz or 56 Gbps, contained in a compact yet robust automotive grade housing.
Apart from ensuring high-bitrate data transmission and savings on installation space and weight, a further major advantage of this connector system is its modularity, providing the flexibility to support a wide range of Ethernet applications and industry protocols.
The application field of the H-MTD is countless as it can be used with a variety of different cables including Shielded Twisted Pair, Unshielded Twisted Pair and new High-Performance cables. With H-MTD the customer can count on an interface that accommodates future vehicle networks, applications and protocols.
