Four Port HMTD Male B Code R/A PCB Mount Connector

Name: Four Port HMTD Male B Code R/A PCB Mount Connector
Brand: Renhotec
SKU: 33-1402-1543-B

SKU 33-1402-1543-B Category Automotive Ethernet Connectors

Product Files

Open drawing and specification files.

Catalog PDF

OEM Compatibility & Manufacturer Part Number Reference

RenhotecRF 33-1402-1543-B can be used as a compatible alternative for the following manufacturer part numbers after drawing and mating-interface verification.

RenhotecRF Part No.	33-1402-1543-B
Rosenberger Part No.	E6S204-40MT5-B

Manufacturer names and part numbers are used for compatibility reference only. Final compatibility should be confirmed by drawing, key code, impedance, and mounting dimensions.

Product Type	Connector
Key Code	B
Mount Type	Board Mount
Position Count	8
Product Type	Connector	Key Code	B
Mount Type	Board Mount	Position Count	8

Product Specification

Cable Color	White
Connector Type	Plug
Contact Finish	Gold Plated
Contact Material	Brass
Frequency - Max	DC to 10 GHz
Impedance	100 Ω
Insulator Material	PTFE
Orientation	Right Angle
Plastic Housing	PA66
Shell Finish	Nickel Plated
Shell Material	Brass
Cable Color	White	Connector Type	Plug
Contact Finish	Gold Plated	Contact Material	Brass
Frequency - Max	DC to 10 GHz	Impedance	100 Ω
Insulator Material	PTFE	Orientation	Right Angle
Plastic Housing	PA66	Shell Finish	Nickel Plated
Shell Material	Brass

Product Type	Connector
Cable Color	White
Connector Type	Plug
Contact Finish	Gold Plated
Contact Material	Brass
Frequency - Max	DC to 10 GHz
Impedance	100 Ω
Insulator Material	PTFE
Key Code	B
Mount Type	Board Mount
Orientation	Right Angle
Plastic Housing	PA66
Position Count	8
Shell Finish	Nickel Plated
Shell Material	Brass

H-MTD Automotive Ethernet Connectors

H-MTD is a differential connector system for high-speed data transmission of up to 20 GHz or 56 Gbps, contained in a compact yet robust automotive grade housing.
Apart from ensuring high-bitrate data transmission and savings on installation space and weight, a further major advantage of this connector system is its modularity, providing the flexibility to support a wide range of Ethernet applications and industry protocols.
The application field of the H-MTD is countless as it can be used with a variety of different cables including Shielded Twisted Pair, Unshielded Twisted Pair and new High-Performance cables. With H-MTD the customer can count on an interface that accommodates future vehicle networks, applications and protocols.
