E6S10A-1CAZ5-Z to E6S10A-1CAZ5-Z Cable – RHT-605-20618
OEM Compatibility & Manufacturer Part Number Reference
RenhotecRF RHT-605-20618 can be used as a compatible alternative for the following manufacturer part numbers after drawing and mating-interface verification.
| RenhotecRF Part No. | RHT-605-20618 |
| Rosenberger Part No. | 1st Connector: E6S10A-1CAZ5-Z, 2nd Connector: E6S10A-1CAZ5-Z |
Manufacturer names and part numbers are used for compatibility reference only. Final compatibility should be confirmed by drawing, key code, impedance, and mounting dimensions.
-
High-Frequency Performance: Supports data transmission up to 10 GHz with precise 100 Ohms differential impedance for automotive high-bandwidth networks.
-
Standardized Male Connectors: Equipped with dual E6S10A-1CAZ5-Z Plug (Male) connectors featuring Universal Key Code Z in Water Blue.
-
Compact & Flexible Routing: Integrated with a 2000mm GG 2Speed® 251 cable featuring a 4.0 mm outer diameter for effortless installation.
Product Specification
| 1st Connector | E6S10A-1CAZ5-Z |
||
|---|---|---|---|
| 2nd Connector | E6S10A-1CAZ5-Z |
||
| Color | Water blue |
||
| Impedance | 100Ω |
||
| Cable Type | GG 2Speed® 251 |
||
| Insulation Resistance | ≥ 100 MΩ |
||
| Temperature Range | -40 °C to +105 °C |
||
| Outer Contact Resistance | ≤ 7.5 mΩ |
||
| Working Voltage | ≤ 60 V DC |
||
| Cable length | 2000mm |
||
| 1st Connector | E6S10A-1CAZ5-Z |
2nd Connector | E6S10A-1CAZ5-Z |
| Color | Water blue |
Impedance | 100Ω |
| Cable Type | GG 2Speed® 251 |
Insulation Resistance | ≥ 100 MΩ |
| Temperature Range | -40 °C to +105 °C |
Outer Contact Resistance | ≤ 7.5 mΩ |
| Working Voltage | ≤ 60 V DC |
Cable length | 2000mm |
| 1st Connector Key Code | Z |
||
|---|---|---|---|
| 2nd Connector Key Code | Z |
||
| 1st Contact Gender | Plug |
||
| 2nd Contact Gender | Plug |
||
| Cable Diameter | REF4.0mm |
||
| Frequency | DC to 10 GHz |
||
| Return loss | ≥ 30 dB, 0.01 GHz to 3 GHz; ≥ 25 dB, 3 GHz to 6 GHz; ≥ 20 dB, 6 GHz to 10 GHz |
||
| 1st Connector Key Code | Z |
2nd Connector Key Code | Z |
| 1st Contact Gender | Plug |
2nd Contact Gender | Plug |
| Cable Diameter | REF4.0mm |
Frequency | DC to 10 GHz |
| Return loss | ≥ 30 dB, 0.01 GHz to 3 GHz; ≥ 25 dB, 3 GHz to 6 GHz; ≥ 20 dB, 6 GHz to 10 GHz |
| 1st Connector | E6S10A-1CAZ5-Z |
|---|---|
| 2nd Connector | E6S10A-1CAZ5-Z |
| 1st Connector Key Code | Z |
| 2nd Connector Key Code | Z |
| 1st Contact Gender | Plug |
| 2nd Contact Gender | Plug |
| Color | Water blue |
| Impedance | 100Ω |
| Cable Type | GG 2Speed® 251 |
| Cable Diameter | REF4.0mm |
| Cable Jacket | PVC |
| Frequency | DC to 10 GHz |
| Insulation Resistance | ≥ 100 MΩ |
| Temperature Range | -40 °C to +105 °C |
| Return loss | ≥ 30 dB, 0.01 GHz to 3 GHz; ≥ 25 dB, 3 GHz to 6 GHz; ≥ 20 dB, 6 GHz to 10 GHz |
| Signal Contact Resistance | ≤ 10 mΩ |
| Outer Contact Resistance | ≤ 7.5 mΩ |
| Working Voltage | ≤ 60 V DC |
| Cable length | 2000mm |
Drawing for E6S10A-1CAZ5-Z TO E6S10A-1CAZ5-Z CABLEDownload
