R/A SMP Jack for RG405 Cable – RHT-628-0013
Right-angle SMP jack, 50Ω, designed for RG405 cable with crimp termination, low-profile right-angle body supports high-density installations, maintains consistent impedance across 18 GHz bandwidth, ideal for aerospace, defense, and broadband wireless infrastructure.
Product Specification
| RF Series | SMP Type |
||
|---|---|---|---|
| Orientation | Right Angle |
||
| Connector Type | Jack |
||
| Suitable Cable | RG405 |
||
| Contact Type | Female Pin |
||
| Contact Material | Brass |
||
| Contact Finish | Gold Plated |
||
| Shell Material | Brass |
||
| Shell Finish | Gold Plated |
||
| Insulator Material | PTFE |
||
| Impedance | 50 ohm |
||
| Frequency Range | 0-3GHz |
||
| VSWR | 1.3 MAX |
||
| Dielectric Withstanding Voltage | 750 V |
||
| Insulation Resistance | 1000MΩ Min |
||
| Temperature Range | -40°C to +125°C |
||
| RF Series | SMP Type |
Orientation | Right Angle |
| Connector Type | Jack |
Suitable Cable | RG405 |
| Contact Type | Female Pin |
Contact Material | Brass |
| Contact Finish | Gold Plated |
Shell Material | Brass |
| Shell Finish | Gold Plated |
Insulator Material | PTFE |
| Impedance | 50 ohm |
Frequency Range | 0-3GHz |
| VSWR | 1.3 MAX |
Dielectric Withstanding Voltage | 750 V |
| Insulation Resistance | 1000MΩ Min |
Temperature Range | -40°C to +125°C |
| Cap Material | Brass |
||
|---|---|---|---|
| Cap Finish | Gold Plated |
||
| Cap Material | Brass |
Cap Finish | Gold Plated |
| RF Series | SMP Type |
|---|---|
| Orientation | Right Angle |
| Connector Type | Jack |
| Suitable Cable | RG405 |
| Contact Type | Female Pin |
| Contact Material | Brass |
| Contact Finish | Gold Plated |
| Shell Material | Brass |
| Shell Finish | Gold Plated |
| Insulator Material | PTFE |
| Cap Material | Brass |
| Cap Finish | Gold Plated |
| Impedance | 50 ohm |
| Frequency Range | 0-3GHz |
| VSWR | 1.3 MAX |
| Dielectric Withstanding Voltage | 750 V |
| Insulation Resistance | 1000MΩ Min |
| Temperature Range | -40°C to +125°C |
The SMP interface, similar in size to MMCX connectors, supports frequencies from DC to 40 GHz. Frequently employed in compact high-frequency coaxial modules, this interface comes in push-on and snap-on mating variations.
Features
- Full detent, limited detent, smooth bore or catcher’s mitt
- Standard surface mount (versus swept contact) for best performance
- 50 ohm impedance
- Performance to 40 GHz
- Cable-to-board or board-to-board applications
- Push-on interface for quick installation, or blind mate
SMP Connector Types
Cable Mount
Panel Mount
SMP Adaptor
Applications
- Antennas
- Broadband
- Instrumentation
- Medical
- Quantum Computing
