E6K10A-1CAZ5-Z to E6K14M-1CAZ5-Y for GG 2Speed® 251, L=7M
OEM Compatibility & Manufacturer Part Number Reference
RenhotecRF RHT-605-9794 can be used as a compatible alternative for the following manufacturer part numbers after drawing and mating-interface verification.
| RenhotecRF Part No. | RHT-605-9794 |
| Rosenberger Part No. | 1st Connector E6K10A-1CAZ5-Z; 2nd Connector E6K14M-1CAZ5-Y |
Manufacturer names and part numbers are used for compatibility reference only. Final compatibility should be confirmed by drawing, key code, impedance, and mounting dimensions.
Product Specification
| 1st Connector | E6K10A-1CAZ5-Z |
||
|---|---|---|---|
| 1st Connector Orientation | Straight |
||
| 1st Contact Type | Female Pin |
||
| 2nd Connector | E6K14M-1CAZ5-Y |
||
| 2nd Connector Orientation | Straight |
||
| 2nd Contact Type | Female Pin |
||
| Frequency Range | DC to 10 GHz |
||
| Insulation Resistance | ≥ 100 MΩ |
||
| Impedance | 100Ω |
||
| Insulator Material | PBT |
||
| Contact Material | Bronze |
||
| Plastic Housing | PBT-GF20 |
||
| 1st Connector | E6K10A-1CAZ5-Z |
1st Connector Orientation | Straight |
| 1st Contact Type | Female Pin |
2nd Connector | E6K14M-1CAZ5-Y |
| 2nd Connector Orientation | Straight |
2nd Contact Type | Female Pin |
| Frequency Range | DC to 10 GHz |
Insulation Resistance | ≥ 100 MΩ |
| Impedance | 100Ω |
Insulator Material | PBT |
| Contact Material | Bronze |
Plastic Housing | PBT-GF20 |
| Operating Voltage VDC | ≤ 60 |
||
|---|---|---|---|
| Return loss | ≥ 30 dB, 0.01 GHz to 3 GHz; ≥ 25 dB, 3 GHz to 6 GHz; ≥ 20 dB, 6 GHz to 10 GHz |
||
| Operation Temperature | -40℃~ +105℃ |
||
| Operating Voltage VDC | ≤ 60 |
Return loss | ≥ 30 dB, 0.01 GHz to 3 GHz; ≥ 25 dB, 3 GHz to 6 GHz; ≥ 20 dB, 6 GHz to 10 GHz |
| Operation Temperature | -40℃~ +105℃ |
| 1st Connector | E6K10A-1CAZ5-Z |
|---|---|
| 1st Connector Orientation | Straight |
| 1st Contact Type | Female Pin |
| 2nd Connector | E6K14M-1CAZ5-Y |
| 2nd Connector Orientation | Straight |
| 2nd Contact Type | Female Pin |
| Frequency Range | DC to 10 GHz |
| Insulation Resistance | ≥ 100 MΩ |
| Operating Voltage VDC | ≤ 60 |
| Return loss | ≥ 30 dB, 0.01 GHz to 3 GHz; ≥ 25 dB, 3 GHz to 6 GHz; ≥ 20 dB, 6 GHz to 10 GHz |
| Impedance | 100Ω |
| Insulator Material | PBT |
| Contact Material | Bronze |
| Operation Temperature | -40℃~ +105℃ |
| Plastic Housing | PBT-GF20 |
Drawing for E6K10A-1CAZ5-Z to E6K14M-1CAZ5-Y for GG 2Speed® 251
