12 V / 24 V, 11 Position, Automotive Housing for Male Terminals, Wire-to-Wire, 4 mm [.157 in] Centerline, Black, Wire & Cable, Hybrid

Termination Point	Wire & Cable
Connector System	Cable-to-Cable \| Wire-to-Wire
Sealable	No
Row Count	4
Position Count	11
Key Code	D
Pin Diameter	.4 mm [ .016 in ]
Mount Type	Cable Mount (Free-Hanging)
Circuit Application	Power
Package Qty	600
Operating Voltage VDC	24
Tab Width	1.2 mm [ .047 in ]
Max Temperature	105 °C [ 221 °F ]
Package Method	Carton
Primary Lock	Integrated in Housing
Housing Type	Housing for Female Terminals
Position Assurance	No
Nominal Voltage V	12 \| 24
Connector Shape	Rectangular
Primary Color	Blue
Contact Size	.4mm \| 1.2mm
Mating Alignment	With
Alignment Type	Keyed
Termination Point	Wire & Cable	Connector System	Cable-to-Cable \| Wire-to-Wire
Sealable	No	Row Count	4
Position Count	11	Key Code	D
Pin Diameter	.4 mm [ .016 in ]	Mount Type	Cable Mount (Free-Hanging)
Circuit Application	Power	Package Qty	600
Operating Voltage VDC	24	Tab Width	1.2 mm [ .047 in ]
Max Temperature	105 °C [ 221 °F ]	Package Method	Carton
Primary Lock	Integrated in Housing	Housing Type	Housing for Female Terminals
Position Assurance	No	Nominal Voltage V	12 \| 24
Connector Shape	Rectangular	Primary Color	Blue
Contact Size	.4mm \| 1.2mm	Mating Alignment	With
Alignment Type	Keyed

Termination Point	Wire & Cable
Connector System	Cable-to-Cable \| Wire-to-Wire
Sealable	No
Row Count	4
Position Count	11
Key Code	D
Contact Type	Receptacle
Pin Diameter	.4 mm [ .016 in ]
Mount Type	Cable Mount (Free-Hanging)
Circuit Application	Power
Package Qty	600
Operating Voltage VDC	24
Tab Width	1.2 mm [ .047 in ]
Max Temperature	105 °C [ 221 °F ]
Temperature Range	-40 – 105 °C [ -40 – 221 °F ]
Package Method	Carton
Primary Lock	Integrated in Housing
Housing Type	Housing for Female Terminals
Position Assurance	No
Nominal Voltage V	12 \| 24
Connector Shape	Rectangular
Primary Color	Blue
Contact Size	.4mm \| 1.2mm
Mating Alignment	With
Alignment Type	Keyed
