Wire-to-Wire, 180° Cable Exit, 1 Position, Shielded, Housing for Female Terminals, Crimp, Signal, FAKRA, Data Connectivity Housings
Ensure reliable data connectivity with this shielded FAKRA housing. It solves signal interference issues by providing a secure, 180° wire-to-wire crimp connection for female terminals in demanding automotive and telecom applications.
With advancements in telematics, high-speed imaging, and smart mobility, RF communication systems have become integral components in today’s automotive, trucking, watercraft, and off-road markets. To ensure high levels of electrical and mechanical performance for telematics and GMSL-based ADAS applications, the worldwide automotive industries have standardized high-performing RF connectors based on FAKRA and USCAR standards.
Featuring specialized color-coding and unique mechanical keying to prevent mis-mating, our FAKRA components—including housings, headers, and terminals—are designed to perform up to 6 GHz. This makes them an ideal solution for high-bandwidth protocols like GMSL2 and FPD-Link III, while meeting the rigorous environmental requirements of the global automotive industry.
PCB End (Male)
Cable End (Male)
Cable End (Female)
- Secure primary locking system with tactile and audible locking
- Shock and vibration resistant coded housing
- Protection against unintentional opening by protective bar and protective strips
- High axial holding power of the coaxial insert due to secondary locking
- Mechanical and color coding system with 14 different codes
- Fastening groove for cable connectors for chassis mounting
- Coaxial insert and cable freely rotatable in the housing
- Pre-assembly lock guarantees correct position of the coaxial inserts in the housing
- Efficient, automated further processing option
- Customized packaging possible
 |
 |
 |
 |
 |
 |
 |
|
| Code | A | B | C | D | E | F | G |
| Color | Deep Black | Cream White | Signal Blue | Bordeaux Violet | Leaf Green | Brown | Blue Gray |
| Application | Radio with phantom supply | Radio without phantom supply | GPS telematics or navigation | GSM Cellular Phone | TV (UHF) | TV (VHF) | SDARS terrestrial |
 |
 |
 |
 |
 |
 |
 |
|
| Code | H | I | K | L | M | N | Z |
| Color | Violet | Beige | Curry Yellow | Carmine Red | Pastel Orange | Pastel Green | Water Blue |
| Application | GPS telematics and navigation | Bluetooth Controlled Parking Heating |
SDARS satellite | Not defined | Keyless entry Tire pressure monitoring |
Not defined | Neutral |
