Tab Terminal,0.8 mm Tab Width, Tin (Sn),0.25 mm Tab Thickness, Unsealed, Terminates To Wire & Cable, FAKRA

This 0.8mm Tab Terminal with a 0.25mm tin-plated tab provides a reliable, unsealed connection for FAKRA cable assemblies. It solves loose or inconsistent terminations by ensuring a precise, secure crimp to wire and cable, improving signal integrity and assembly durability in automotive and telecom applications.

Description
Attributes

With advancements in telematics and automotive communications technology, RF communication systems have become integral components in today’s automotive, trucking, watercraft, motorcycle, and off-road construction markets. To ensure high levels of electrical and mechanical performance for telematics applications, the worldwide automotive industries have standardized a high-performing, cost-effective RF connector based on the FAKRA and USCAR standards.

Embedded within a plastic housing which features multiple color codes for easy identification and unique keying to prevent mis-mating, FAKRA connectors are designed to perform up to 6 GHz and meet the particular mechanical and environmental requirements of the automotive industry.

PCB End (Male)

Cable End (Male)

Cable End (Female)

Secure primary locking system with tactile and audible locking
Shock and vibration resistant coded housing
Protection against unintentional opening by protective bar and protective strips
High axial holding power of the coaxial insert due to secondary locking
Mechanical and color coding system with 14 different codes

Fastening groove for cable connectors for chassis mounting
Coaxial insert and cable freely rotatable in the housing
Pre-assembly lock guarantees correct position of the coaxial inserts in the housing
Efficient, automated further processing option
Customized packaging possible


Code	A	B	C	D	E	F	G
Color	Deep Black	Cream White	Signal Blue	Bordeaux Violet	Leaf Green	Brown	Blue Gray
Application	Radio with phantom supply	Radio without phantom supply	GPS telematics or navigation	GSM Cellular Phone	TV (UHF)	TV (VHF)	SDARS terrestrial

Code	H	I	K	L	M	N	Z
Color	Violet	Beige	Curry Yellow	Carmine Red	Pastel Orange	Pastel Green	Water Blue
Application	GPS telematics and navigation	Bluetooth Controlled Parking Heating	SDARS satellite	Not defined	Keyless entry Tire pressure monitoring	Not defined	Neutral

Our Advantages

Physical factory

Having a professional production team, selfproduced and self sold

Quality assurance

Through strict qualitycontrol, ensure quality

Customized

We can customize diff-erent specifications ac-cording to your needs

After sales system

Actively follow up andpromptly address anyissues

Production Process

1. Put forward demand

2. Sketch design

3. Production equipment

4. Production measurement

5. Product assembly

6. Quality test

7. Product packaging

8. Product packag box

9. Deliver goods

Termination Point	Wire & Cable
Connector System	Wire-to-Wire
Sealable	No
Row Count	1
Position Count	1
Center Contact	With
Contact Plating	Gold (Au)
Center Contact Plating	Gold (Au)
Mount Type	Cable Mount (Free-Hanging)
Housing Color	Gray
Shielded	No
Circuit Application	Signal
Package Qty	3000
Body Material	PBT GF
Max Temperature	105 °C [ 221 °F ]
Package Method	Bag
Primary Lock	Clean Body
Housing Type	Housing for Male Terminals
Snap Lock	Without
Cable Exit Angle	180°
Cable Termination	Crimp
Frequency Range GHz	0 – 3
Dielectric Material	PBT
Position Assurance	No
Standards Certified	SAE/USCAR-17
Operating Voltage VAC	800
Termination Point	Wire & Cable	Connector System	Wire-to-Wire
Sealable	No	Row Count	1
Position Count	1	Center Contact	With
Contact Plating	Gold (Au)	Center Contact Plating	Gold (Au)
Mount Type	Cable Mount (Free-Hanging)	Housing Color	Gray
Shielded	No	Circuit Application	Signal
Package Qty	3000	Body Material	PBT GF
Max Temperature	105 °C [ 221 °F ]	Package Method	Bag
Primary Lock	Clean Body	Housing Type	Housing for Male Terminals
Snap Lock	Without	Cable Exit Angle	180°
Cable Termination	Crimp	Frequency Range GHz	0 – 3
Dielectric Material	PBT	Position Assurance	No
Standards Certified	SAE/USCAR-17	Operating Voltage VAC	800

Product Specification

Contact Type	Socket
Temperature Range	-40 – 105 °C [ -40 – 221 °F ]
Cable Type	RG 174 \| RG 316
Contact Type	Socket	Temperature Range	-40 – 105 °C [ -40 – 221 °F ]
Cable Type	RG 174 \| RG 316

Termination Point	Wire & Cable
Connector System	Wire-to-Wire
Sealable	No
Row Count	1
Position Count	1
Contact Type	Socket
Center Contact	With
Contact Plating	Gold (Au)
Center Contact Plating	Gold (Au)
Mount Type	Cable Mount (Free-Hanging)
Housing Color	Gray
Shielded	No
Circuit Application	Signal
Package Qty	3000
Body Material	PBT GF
Max Temperature	105 °C [ 221 °F ]
Temperature Range	-40 – 105 °C [ -40 – 221 °F ]
Package Method	Bag
Primary Lock	Clean Body
Housing Type	Housing for Male Terminals
Snap Lock	Without
Cable Exit Angle	180°
Cable Termination	Crimp
Cable Type	RG 174 \| RG 316
Frequency Range GHz	0 – 3
Dielectric Material	PBT
Position Assurance	No
Standards Certified	SAE/USCAR-17
Operating Voltage VAC	800
