SMP Jack to TD RF Cable Assemblies with RG405 Cable – EB-101-0277

SKU EB-101-0277 Category High Frequency Cable Assemblies, SMP Cable Assemblies

SMP Jack to TD RF cable assemblies with premium RG405 cable for enhanced signal integrity
RG405 cable ensures low-loss performance and excellent high-frequency transmission
Durable connectors with gold plating for superior conductivity and reliability
Perfect for industrial, communication systems, and RF applications
Versatile solution for connecting SMP and TD devices in demanding environments

Attributes
Description

Product Specification

RF Cable Style	SMP to TD
RF Cable 1st Connector	SMP Jack
1st Contact Type	Female Pin
1st Connector Orientation	Right Angle
RF Cable 2nd Connector	TD
Impedance	50 ohm
Cable Color	Blue
Frequency Range	DC-14GHz
Temperature Range	-40°C to +85°C
Cable Type	RG405
RF Cable Style	SMP to TD	RF Cable 1st Connector	SMP Jack
1st Contact Type	Female Pin	1st Connector Orientation	Right Angle
RF Cable 2nd Connector	TD	Impedance	50 ohm
Cable Color	Blue	Frequency Range	DC-14GHz
Temperature Range	-40°C to +85°C	Cable Type	RG405

RF Cable Style	SMP to TD
RF Cable 1st Connector	SMP Jack
1st Contact Type	Female Pin
1st Connector Orientation	Right Angle
RF Cable 2nd Connector	TD
Impedance	50 ohm
Cable Color	Blue
Frequency Range	DC-14GHz
Temperature Range	-40°C to +85°C
Cable Type	RG405

Why Choose RENHOTEC

RENHOTEC supports custom coaxial cable assemblies for prototype development, sample evaluation, and small-batch production.

100% VNA Testing

VNA testing for applicable cable assemblies to evaluate electrical performance against specified requirements.

Prototype to Production

Support for sample development, prototype evaluation, and small-batch production.

Flexible Cable Options

Cable types, lengths, and assembly structures can be specified according to project requirements.

High-Frequency Coaxial Cable Assemblies

RENHOTEC provides high-frequency coaxial cable assemblies for RF and microwave applications, including equipment interconnections, test and measurement systems, and compact electronic modules. Designed around high-frequency connector interfaces and coaxial cable configurations, these assemblies support different connection layouts, frequency requirements, and installation constraints.

Six high-frequency RF cable assemblies of various sizes arranged diagonally. The connectors are labeled 1.0mm, 1.85mm, 2.4mm, 2.92mm, 3.5mm, and SMP. Cables come in gray, blue, purple, and black with metallic connectors and black heat-shrink boots.

Connector Interface Options

SMP to SMP and Mini-SMP to Mini-SMP
SMA to SMP, Mini-SMP, or SSMP
1.85mm to Mini-SMP
2.4mm to SMP, Mini-SMP, or SMPS
2.92mm to SMPS or SSMP
Other compatible interface combinations based on project requirements

Coaxial Cable Options for Custom Assemblies

RENHOTEC offers a range of RF coaxial cables for SMP series cable assemblies, including flexible, semi-rigid, and other cable configurations. Cable selection and connector compatibility depend on the specific assembly requirements.
