Short Fakra D Code Male R/A PCB Mount Connector
OEM Compatibility & Manufacturer Part Number Reference
RenhotecRF 33-1401-0679 can be used as a compatible alternative for the following manufacturer part numbers after drawing and mating-interface verification.
| RenhotecRF Part No. | 33-1401-0679 |
| Rosenberger Part No. | 59S20K-40MT5-D |
| TE Connectivity Alternative | 2291392-4 |
Manufacturer names and part numbers are used for compatibility reference only. Final compatibility should be confirmed by drawing, key code, impedance, and mounting dimensions.
| Part Number | 33-1401-0679 |
||
|---|---|---|---|
| Key Code | H |
||
| Part Number | 33-1401-0679 |
Key Code | H |
Product Specification
| Connector Type | Plug |
||
|---|---|---|---|
| Orientation | Right Angle |
||
| Mounting Type | Panel Mount |
||
| Mounting Feature | PCB |
||
| Cable Color | Purple |
||
| Number of Ports | 1 |
||
| Plastic Housing | PA66 |
||
| Shell Material | Brass |
||
| Shell Finish | Nickel Plated |
||
| Insulator Material | PTFE |
||
| Contact Material | Brass |
||
| Contact Finish | Gold Plated |
||
| Impedance | 50Ω |
||
| Frequency - Max | DC～6GHz |
||
| Connector Type | Plug |
Orientation | Right Angle |
| Mounting Type | Panel Mount |
Mounting Feature | PCB |
| Cable Color | Purple |
Number of Ports | 1 |
| Plastic Housing | PA66 |
Shell Material | Brass |
| Shell Finish | Nickel Plated |
Insulator Material | PTFE |
| Contact Material | Brass |
Contact Finish | Gold Plated |
| Impedance | 50Ω |
Frequency - Max | DC～6GHz |
| 基本单位 | 个 |
|---|---|
| Part Number | 33-1401-0679 |
| Connector Type | Plug |
| Orientation | Right Angle |
| Mounting Type | Panel Mount |
| Mounting Feature | PCB |
| Cable Color | Purple |
| Key Code | H |
| Number of Ports | 1 |
| Plastic Housing | PA66 |
| Shell Material | Brass |
| Shell Finish | Nickel Plated |
| Insulator Material | PTFE |
| Contact Material | Brass |
| Contact Finish | Gold Plated |
| Impedance | 50Ω |
| Frequency - Max | DC～6GHz |
With advancements in telematics and automotive communications technology, RF communication systems have become integral components in today’s automotive, trucking, watercraft, motorcycle, and off-road construction markets. To ensure high levels of electrical and mechanical performance for telematics applications, the worldwide automotive industries have standardized a high-performing, cost-effective RF connector based on the FAKRA and USCAR standards.
Embedded within a plastic housing which features multiple color codes for easy identification and unique keying to prevent mis-mating, FAKRA connectors are designed to perform up to 6 GHz and meet the particular mechanical and environmental requirements of the automotive industry.
PCB End (Male)
Cable End (Male)
Cable End (Female)
- Secure primary locking system with tactile and audible locking
- Shock and vibration resistant coded housing
- Protection against unintentional opening by protective bar and protective strips
- High axial holding power of the coaxial insert due to secondary locking
- Mechanical and color coding system with 14 different codes
- Fastening groove for cable connectors for chassis mounting
- Coaxial insert and cable freely rotatable in the housing
- Pre-assembly lock guarantees correct position of the coaxial inserts in the housing
- Efficient, automated further processing option
- Customized packaging possible
 |
 |
 |
 |
 |
 |
 |
|
| Code | A | B | C | D | E | F | G |
| Color | Deep Black | Cream White | Signal Blue | Bordeaux Violet | Leaf Green | Brown | Blue Gray |
| Application | Radio with phantom supply | Radio without phantom supply | GPS telematics or navigation | GSM Cellular Phone | TV (UHF) | TV (VHF) | SDARS terrestrial |
 |
 |
 |
 |
 |
 |
 |
|
| Code | H | I | K | L | M | N | Z |
| Color | Violet | Beige | Curry Yellow | Carmine Red | Pastel Orange | Pastel Green | Water Blue |
| Application | GPS telematics and navigation | Bluetooth Controlled Parking Heating |
SDARS satellite | Not defined | Keyless entry Tire pressure monitoring |
Not defined | Neutral |
