MCX Connector Male Crimp Type RG316 Cable 50ohm – RHT-617-0150

High-quality MCX male crimp connector designed for RG316 cables with 50ohm impedance. Ensure reliable signal transmission in various applications with this durable and easy-to-install connector.

MCX / MMCX (Micro-Miniature Coaxial) connector are developed in Europe during the 1980s to 1990s, broadband capability of DC to 6 GHz and secure, fast and easy snap-on/snap-off coupling. Conforms to the European CECC 22000 specification.With small size, less weight, compact structure and easy fit, they are widely used in small sized communication equipment.

Broadband performance with low reflection

Quick connect/disconnect snap-on mating reduces installation time

Available in straight and right angle plugs and printed circuit board connectors

High-quality solution at a low cost

Complete Variety

MCX Connector

Crimp Type
