MCX Connector Male Crimp RG316 Cable Type 50ohm – RHT-617-1012

High-quality MCX connector with male crimp designed for RG316 cable type, ensuring reliable 50 ohm connection. Ideal for various applications requiring secure and efficient signal transmission.

The connector was developed in Europe from the 1980s to the 1990s. It adopts a push-in coupling method and is suitable for quick insertion and removal. Ultra-micro size, small size, lightweight, compact structure, widely used in small communication equipment with space constraints.

MCX connectors are approximately 30% smaller than SMB connectors, are available in both 50 and 75 Ohm versions, and provide good electrical performance to 6 GHz.

Mainly applicable to aerospace and defense, medical, commercial vehicles, telecommunications, data/communications, industrial, etc.

MCX Connector

MMCX Connector

Interface

Application Scenarios



Product Specification

RF Series

MCX Type

Connector Type

Plug

Orientation

Right Angle

Contact Type

Male Pin

Contact Termination Style

Crimp

Shield Termination

Crimp

Mounting Type

Cable Mount

Cable Type

RG316

Fastening Type

Push-Pull

Number of Ports

1

Impedance

50 ohm

Frequency - Max

6GHz

Shell Material

Copper Alloy

Shell Finish

Gold Plated

Insulator Material

Teflon White

Contact Material

Brass

Contact Finish

Gold Plated

Rated Voltage

500 Volts RMS Max Continuous

Dielectric Withstanding Voltage

1000 VRMS Max

Insultation Resistance

500 MΩ Min

Center Contact Resistance

5 MΩ Min

Outer Contact Resistance

1 MΩ Min

Temperature Range

-65℃ to +165℃

Mating Durability

≥ 500 Cycles

VSWR

≤1.15 (DC to 4 GHz), ≤1.40 (4 to 6 GHz)

Vibration

MIL-STD-202 Meth. 204

Corrosion Resistance

MIL-STD-202 Meth. 101

RF Series

MCX Type

Connector Type

Plug

Orientation

Right Angle

Contact Type

Male Pin

Contact Termination Style

Crimp

Shield Termination

Crimp

Mounting Type

Cable Mount

Cable Type

RG316

Fastening Type

Push-Pull

Number of Ports

1

Impedance

50 ohm

Frequency - Max

6GHz

Shell Material

Copper Alloy

Shell Finish

Gold Plated

Insulator Material

Teflon White

Contact Material

Brass

Contact Finish

Gold Plated

Rated Voltage

500 Volts RMS Max Continuous

Dielectric Withstanding Voltage

1000 VRMS Max

Insultation Resistance

500 MΩ Min

Center Contact Resistance

5 MΩ Min

Outer Contact Resistance

1 MΩ Min

Temperature Range

-65℃ to +165℃

Mating Durability

≥ 500 Cycles

VSWR

≤1.15 (DC to 4 GHz), ≤1.40 (4 to 6 GHz)

Vibration

MIL-STD-202 Meth. 204

Corrosion Resistance

MIL-STD-202 Meth. 101

RF Series

MCX Type

Connector Type

Plug

Orientation

Right Angle

Contact Type

Male Pin

Contact Termination Style

Crimp

Shield Termination

Crimp

Mounting Type

Cable Mount

Cable Type

RG316

Fastening Type

Push-Pull

Number of Ports

1

Impedance

50 ohm

Frequency - Max

6GHz

Shell Material

Copper Alloy

Shell Finish

Gold Plated

Insulator Material

Teflon White

Contact Material

Brass

Contact Finish

Gold Plated

Rated Voltage

500 Volts RMS Max Continuous

Dielectric Withstanding Voltage

1000 VRMS Max

Insultation Resistance

500 MΩ Min

Center Contact Resistance

5 MΩ Min

Outer Contact Resistance

1 MΩ Min

Temperature Range

-65℃ to +165℃

Mating Durability

≥ 500 Cycles

VSWR

≤1.15 (DC to 4 GHz), ≤1.40 (4 to 6 GHz)

Vibration

MIL-STD-202 Meth. 204

Corrosion Resistance

MIL-STD-202 Meth. 101
