F Type Connector Jack Right Angle Solder PCB Mount Through Hole – RHT-611-0504
Right Angle F Type Connector Jack for PCB mount, designed for solder through-hole installation. Ideal for cable TV, satellite, and broadband applications. Provides reliable signal transmission in tight spaces, simplifying board layout and installation. Its durable construction supports long-term performance in communication equipment and set-top boxes.
Product Specification
| RF Series | F Type |
||
|---|---|---|---|
| Fastening Type | Threaded |
||
| Orientation | Right Angle |
||
| Mounting Type | PCB Mount |
||
| Impedance | 75 ohm |
||
| Insulator Material | Polypropylene |
||
| Contact Material | Brass |
||
| Temperature Range | -55°C to +155°C |
||
| Insultation Resistance | 5000 Ohms min |
||
| RF Series | F Type |
Fastening Type | Threaded |
| Orientation | Right Angle |
Mounting Type | PCB Mount |
| Impedance | 75 ohm |
Insulator Material | Polypropylene |
| Contact Material | Brass |
Temperature Range | -55°C to +155°C |
| Insultation Resistance | 5000 Ohms min |
| Gender | Female |
||
|---|---|---|---|
| Polarity | Female Pin |
||
| Termination | Solder |
||
| Mount Feature | Through Hole |
||
| Port Numbers | 1 |
||
| Body Material | Zinc |
||
| Body Plating | Nickel Plating |
||
| Contact Plating | SN |
||
| Gender | Female |
Polarity | Female Pin |
| Termination | Solder |
Mount Feature | Through Hole |
| Port Numbers | 1 |
Body Material | Zinc |
| Body Plating | Nickel Plating |
Contact Plating | SN |
| RF Series | F Type |
|---|---|
| Fastening Type | Threaded |
| Orientation | Right Angle |
| Gender | Female |
| Polarity | Female Pin |
| Termination | Solder |
| Mounting Type | PCB Mount |
| Mount Feature | Through Hole |
| Port Numbers | 1 |
| Impedance | 75 ohm |
| Frequency(Max） | 1GHz |
| Body Material | Zinc |
| Body Plating | Nickel Plating |
| Insulator Material | Polypropylene |
| Contact Material | Brass |
| Contact Plating | SN |
| Temperature Range | -55°C to +155°C |
| Insultation Resistance | 5000 Ohms min |
F Type Coaxial Connectors
Own factory
Support customization
Real shooting
STRICTLY SELECT MATERIALS AND GUARD DETAILS
The F connector is a coaxial cable connector widely used in television and radio equipment. It is threaded to provide a reliable electrical connection and resistance to interference, and is commonly used to connect equipment such as antennas, modems, and satellite television receivers.The housing of the F connector is usually made of a metallic material, which helps to minimize signal attenuation and interference.
These connectors typically operate in the frequency range from a few hundred MHz to 3 GHz and are suitable for a wide variety of video and data transmission applications.F connectors are relatively simple to install and are therefore widely used in both home and commercial equipment. When installing, ensure that the connection is dry and clean to maintain optimal signal transmission quality.
Support high frequency transmission, reduce signal loss.
Made of nickel-plated or gold-plated material, anti-corrosion and long life.
Threaded design ensures firm connection and prevents loosening.
Suitable for a variety of coaxial cables, such as RG6, RG59, etc.
